267 SSX DECK PLAN
TYPICAL SSX PROFILE
A - Strong points for anchoring or docking
B - Sling locations
C - Trailering eye
Figure 3.7 256 SSX, 267 SSX
TYPICAL SSX ENGINE COMPARTMENT LAYOUT
1. Bilge Pump
2. Engine
3. Blowers
4. Trim Pump (Merc)
5. Battery
6. Water Tank (optional)
7. Water Pump (optional)
8. Fire Extinguishing System (optional)
9. Steering Helm
10. Fire Port (located on side of motor box)
11. Fuel Tank
12. Euro Manual Pump
