Chaparral 285 SSX - Page 45

3-12
2
6
19
4
4
8
3
17
10
11
21
7
1
14
12
9
15
13
16
18
TYPICAL SSX ENGINE COMPARTMENT LAYOUT
1. Bilge Pump
2. Engine
3. Blowers
4. Trim Pump (Merc)
5. Battery
6. Water Tank (optional)
7. Water Pump (optional)
8. Fire Extinguishing System (optional)
9. Steering Helm
10. Fire Port (located on side of motor box)
11. Fuel Tank
12. Euro Manual Pump
285 SSX Deck Plan View
Fig. 4.0 - 285 SSX
