Char-Broil T-22D User Manual

7
A
B
C
Foldable side shelf
Foldable side shelf
Foldable side shelf
Shoulder screw
1/4"Nut
Right side shelf
Right side shelf
Track
Bracket
D
Attach foldable side shelf brackets to the tracks under right side shelf using one shoulder screw and 1/4" nut
each side, shown A/B.
Pull foldable side shelf outward and press it down, shown C.
Push foldable side shelf toward right side shelf until they meet, shown D.
Only right side shelf shown for assembly, repeat above steps to Install left side shelf with foldable side
shelf.
Rear Side, With
TM
Gear Trax Holes
Front Side,
TM
No Gear Trax Holes
16
