B-2
PARTS LIST
Item QTY Part Name
1 1 SIDE SHELF/LID
2 1 LEFT BODY ASSEMBLY
3 1 RIGHT BODY ASSEMBLY
4 1 SIDE SHELF SUPPORT - REAR
5 2 SIDE SHELF SUPPORT - FRONT
6 2 UPPER RIGHT LEG
7 2 UPPER LEFT LEG
8 4 LOWER LEG
9 4 LEG ADJUSTER SCREW
10 6 STAR GRIP BOLT
11 1 1 LB. TANK SUPPORT BRACKET
HARDWARE NEEDED
Tools Needed: Phillips Head Screwdriver and a 7/16” Nut Driver.
**NOTE: DO NOT fully tighten any bolts until instructed to do so. Tightening too
soon may prohibit parts from tting together. All hex nuts should be on the inside
of the stand unless stated otherwise. Unpack all contents in a well cleared and
padded area.**
Estimated Time: 20 minutes
Hardware Pack #501139
Part No. Description Photo QTY
1/4-20 x 1/2” HEX BOLT 4
A
