Chef UC-PS18-30 - Page 10

Four, (4)
mounting holes
6-1/2”
wide filler
along front
and sides
3-1/4”
4-1/8”
8-1/4”
2-1/2”
5-1/2”
4-1/8”
2”
1” hole
4-1/8”
2”
1” hole
UC-PS18 USER MANUAL 10
RH filler notched
at back corner to
allow plug clrearance
1
2
Cabinet with recessed bottom
36” cabinet (typical)
Cabinet with
recessed bottom
10-1/2” x 3-3/4” hole
CL
18”
2-3/8”
Four, (4)
mounting holes
1
2
Cabinet with flush bottom
36” cabinet (typical)
Cabinet with
flush bottom
10-1/2” x 3-3/4” hole
CL
18”
2-3/8”
3. Rectangular Horizontal Adapter
3-1/4”
4-1/8”
8-1/4”
2-1/2”
5-1/2”
