Chef UC-PS38SS-30 - Page 6

Preparing the Cabinet
UC-PS38 USER MANUAL 6
9”
Cabinet or soffit with flush bottom
30” cabinet (typical)
Cabinet with
flush bottom
12”
(typical)
1-1/4”
2”
1” hole
5”
8”
2-3/8”
2-3/8”
3-1/4”
1-7/8”
Four, (4)
mounting holes
Four, (4)
mounting holes
2
1
Cabinet with recessed bottom
30” cabinet (typical)
Cabinet with
recessed bottom
12”
(typical)
9”x8” hole
CL
1-1/4”
2”
1” hole
5”
9”
8”
1
3-1/2”
wide filler
along front
and sides
8”
2-3/8”
2-3/8”
3-1/4”
1-7/8”
RH filler notched
at back corner to
allow plug clrearance
2
9”x8” hole
CL
8”
