9-52 Driving and Operating
Vehicle Axle Ratio Maximum Trailer Weight GCWR*
G2500 Cargo Van 2WD Long Wheelbase
4.8L V8 3.42 3 266 kg (7,200 lbs) 5 897 kg (13,000 lbs)
6.0L V8 3.42 4 536 kg (10,000 lbs) 7 257 kg (16,000 lbs)
G2500 Passenger Van 2WD Short Wheelbase
4.8L V8 3.42 3 039 kg (6,700 lbs) 5 897 kg (13,000 lbs)
6.0L V8 3.42 4 445 kg (9,800 lbs) 7 257 kg (16,000 lbs)
G3500 Cargo Van 2WD Short Wheelbase
4.8L V8 3.42 3 357 kg (7,400 lbs) 5 897 kg (13,000 lbs)
6.0L V8 3.42 4 536 kg (10,000 lbs) 7 257 kg (16,000 lbs)
G3500 Cargo Van 2WD Long Wheelbase
4.8L V8 3.42 3 221 kg (7,100 lbs) 5 897 kg (13,000 lbs)
6.0L V8 3.42 4 536 kg (10,000 lbs) 7 257 kg (16,000 lbs)
