Assembly
snoitcurtsnI
Parts Included
Prior to assembly, please be sure to identify and sort all parts shown below.
Call 1.800.672.4399 for questions
Please read through all instructions before starting.
1 Bolt
M10 mm x 35 mm
Accessories
A
9 Bolts
M10 mm x 40 mm
B C
1 Bolt
M10 mm x 70 mm
D
4 Double-Sided Bolts
M10 mm x 85 mm
E
8 Bolts
M6 mm x 35 mm
F
5 Bolts
M6 mm x 16 mm
G
1 Bracket
H
1 Bracket
I
1 Bracket
J
1 Screw
M4 mm x 30 mm
K
1 Drywall Anchor
30 mm
1 Baseboard 1 Platform
1 2 3 4 5
1 Platform 1 Apartment
6 7 8 9
1 Perch
5 Scratching Posts
15.75 inch
4 Posts
19.69 inch
4 Posts
15.75 inch
10
11 12 13 14
1 Platform
1 Perch 1 Platform
1 Scratching Post
16.54 inch
1 Rope 4 Posts
10.43 inch
F
1 Washer
6 mm
1
5 mm Allen Wrench
YES YES
