CHI 13102 - Parts and Features

5
Parts and Features
Fabric
Temperature/
OFF ( ) Indicator
1. Spray Nozzle
2. Swivel Water Fill Door
3. Fabric Temperature/OFF
( ) Indicator
4. Spray ( ) and Steam ( )
Buttons
5. Handle
6. Retractable Cord
7. Retractable Cord Button
8. Control Panel
9. Heel Rest
10. Water Window
11. MAX Fill Line
12. Titanium Ceramic
Soleplate
13. Self-Clean Button
14. Adjustable Steam Lever
15. Fabric Temperature
Setting Dial
Retractable Cord
Control Panel
