Installation Instructions FSBIB/FSBI2B
3
DIMENSIONS - FSBI2B
TOOLS / PARTS FOR INSTALLATION
.19
9.7
A
B
RELEASE TAB
(.7)
(10.2)
100°
.39
SECTION A-A
SCALE 2 : 1
DETAIL B
SCALE 1 : 1
KEEPER TAB
A (1)
[iPad™/iPad 2™
Adapter]
B (4)
M4
C (4)
M4 x 20mm
D (4)
M4 x 12mm
