Correct connection Incorrect connection
Earth
(Ground)
Earth
(Ground)
Earth
(Ground)
Earth
(Ground)
Earth
(Ground)
*Cable must contact the base metal directly and contact two earth (ground) cables.
*The earth (ground) cable must be connected diagonally on the base metal (Refer to the diagram below).
