2-6.1 Controls on generator front panel
A Output indicator
During machine output, the red LED will light.
A1 Connection indicator
When the torch and earth (ground) cables have a good connection, the yellow LED will light.
B Output voltage meter
C Output voltage adjustment for stud welding
D STUD torch connector
E SPOT earth (ground) connector
F Control cable connector
A
A1
B
C
DE
F
