R410A DC Inverter Multi-split Technical Manual Outdoor Units
33
GD Chigo Heating & Ventilation Equipment Co., Ltd.
2. Specifications
Outdoor model name
C2OU-14HVR1
C2OU-18HVR1
Power supply
V-ph-Hz
220~240-1-50
220~240-1-50
Electricity supplying type
Outdoor unit supply power
Outdoor unit supply power
Indoor units combination
Single
Double
Single
Double
Cooling
Capacity
Btu/h
7000~12000
14000
7000~12000
18000
Input
W
600~1040
1214
600~1050
1603
Rated current
A
3.0~5.1
6.0
3.0~5.1
7.9
EER
Btu/(h*W)
11.5
11.2
W/W
3.38
3.29
Heating
Capacity
Btu/h
8500~13800
17000
8500~13800
21000
Input
W
660~1084
1343
660~1090
1665
Rated current
A
3.3~5.4
6.6
3.3~5.4
8.2
COP
Btu/(h*W)
12.7
12.6
W/W
3.71
3.70
Max. input consumption
W
1560
1900
1780
2400
Max. current
A
8.1
9.8
9.2
12.4
Compressor
Model
SNB130FGYMC-L1
SNB130FGYMC-L1
Type
DC inverter twin-rotary
DC inverter twin-rotary
Brand
MITSUBISHI
MITSUBISHI
Capacity
Btu/h
14000
14000
Input
W
1245
1245
Rated current (RLA)
A
8.4
8.4
Refrigerant oil
ml
500
500
Fan motor
Model
YDK-60-6P3-3
YDK-60-6P3-3
Brand
CHIGO
CHIGO
Input
W
160
160
Capacitor
μF
3.5
3.5
Speed
r/min
850/530
850/530
Outdoor coil
Number of rows
1.7
1.7
Tube pitch * row pitch
mm
21*13.37
21*13.37
Fin spacing
mm
1.4
1.4
Fin type
Hydrophilic aluminum
Hydrophilic aluminum
Tube diameter and type
mm
Ф7 Inner screw
Ф7 Inner screw
Coil size (W*H*D)
mm
214*640*550
214*640*550
Number of circuits
4
4
Outdoor air flow
m
3
/h
2500
2500
Outdoor noise level
dB(A)
57
57
Outdoor unit
Net dimension (W*H*D)
mm
940*332*608
940*332*608
Packing dimension (W*H*D)
mm
995*415*680
995*415*680
Net / Gross weight
kg
38/41
39/42
Refrigerant
Type
R410a
R410a
Charged volume
g
1150
1450
Throttle type
Electronic expansion valve
Max. pressure(Hi/Lo)
MPa
4.4/2.6
4.4/2.6
Refrigerant piping
(Between each IU and OU)
Liquid side/ Gas side
mm
Ф6.35/Ф9.52
Ф6.35/Ф9.52
Max. pipe length
m
30
30
Max. height difference
m
10
10
Connection wiring
Power wiring
mm
2
1.5
1.5
Signal wiring
mm
2
1
1
Ambient temperature
˚C
-15~46
-15~46
Application area
m
2
26~30
35~43
