Chigo CSG-07HVR1(84) User Manual

R410A DC Inverter Multi-split Technical Manual Outdoor Units
51
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Quantity
No.
Part Name
Quantity
1
Chassis assembly(S214)
1
10.2
DN4 Stop valve A
1
2
Condenser prewelding assembly
1
10.3
DN8 Stop valve A
1
2.1
Two-row condenser
1
10.4
DN8 Stop valve B
1
2.2
Fixed tube of condenser main outlet pipe
1
11
Motor support
1
2.3
Probe copper pipe
1
12
Ironcladasynchronous outdoor
motor
1
2.4
Condenser main outlet pipe
1
13
Axial-flow fan
1
2.5
Merged prewelding assembly of
Condenser
1
14
Connection plate of Motor supports
1
2.6
Distributary prewelding assembly of
condenser
1
15
Plastic grid guard of 2P outdoor unit
1
3
Septum plate
1
16
Right side plate
1
4
Gum ring
1
17
Outdoorelectroniccomponents
1
5
Amorphous inductor
1
17.1
Baseboard of Electric control box
1
6
Compressor
1
17.2
Left connection plate of Electric
control box
1
7
Suction pipe
1
17.3
Right connection plate of Electric
control box
1
8
Prewelding assembly of Exhaust pipe
1
17.4
Filter fixed plate
1
8.1
Exhaust pipe A
1
17.5
Radiating fin fixed plate
1
8.2
Exhaust pipe B
1
17.6
Radiating fin
1
8.3
Antihum device
1
17.7
Outdoor main board assembly
1
8.4
Probe copper pipe
1
17.8
Outdoor module board assembly
1
9
Prewelding assembly of Four-way valve
1
17.9
Monophase filter
1
9.1
Four-way valve
1
18
Panel
1
9.2
Coil kit of Four-way valve
1
19
Front grille
1
9.3
Connecting pipe A of Four-way valve
1
20
Left vertical shaft
1
9.4
Connecting pipe B of Four-way valve
1
21
Large hand-drawn
1
9.5
Connecting pipe C of Four-way valve
1
22
Top cover plate
1
10
Valve seat assembly
1
23
Valve seat guard cover
1
10.1
DN4 Stop valve B
1
