Chillafish QUADie - Assembly Instructions

4
Assembly instrucons
For easy assembly, please use the images in appendix as your reference.
A
B
C
D
E
F
G
Please check that your box contains all parts shown in image A.
Assemble the rear wheels and make sure the bolt is secured.
Insert the steering axle into the frame tube.
Insert the handle bar into the steering axle. Take out the bolt and push
the plasc ring over the steering axle. Make sure the three holes are
aligned.
Insert the hexagonal nut into the hexagonal hole.
Insert the bolt through the aligned holes and secure the bolt using a
screwdriver.
Make sure the snaps on the caps are aligned with the sleeve in the plasc
ring. Click the covering cap into the snap holes.
EN
