E21
Transport conditions
Surrounding temperature: -20°C to 60°C
Surrounding humidity: 5 to 90% rh (With no condensation)
Vibrations: 4.9m/s
2
(10 to 60Hz)
Shocks: 392m/s
2
However these are the factory shipping packing
conditions.
Storage conditions
Surrounding temperature: -20°C to 60°C
However temperature for long term
preservation is 10°C to 30°C.
Surrounding humidity: 5 to 90% rh (With no condensation)
Vibrations: 0m/s
2
Shocks: 0m/s
2
However these are the factory shipping packing
conditions.
Option
[ Transmission signal output]
Number of outputs: (KP1000) Maximum 1 points
(KP2000/3000) Maximum 2 points
Output signal: 4 to 20mA (Load resistance Less than 400Ω)
0 to 1V (Output impedance Approx.10Ω)
(Load resistance More than 50kΩ)
0 to 10V (Output impedance Approx.10Ω)
(Load resistance More than 50kΩ)
Accuracy rating: High accuracy type ±0.1%F
General type ±0.3%FS
Resolution: Approximately 1/30000
Output update period: Approx. 0.1 second
Insulation: Internal circuit is insulated
(More than 20MΩ/500VDC)
Transmission signal outputs are also insulated
[Transmitter power supply] (KP2000 only)
Power supply voltage: 24VDC±10%
Maximum current capacity: Less than 30mA
Insulation: Internal circuit is insulated
(20MΩ or more and 500VDC)
[Communications interface]
Communications points: (KP1000) Maximum 1 points
(KP2000/3000) Maximum 2 points
Communications types: RS232C, RS422A, RS485
Protocol: MODBUS(RTU), MODBUS(ASCII), PRIVATE
Insulation: Internal circuit is insulated
(20MΩ or more and 500VDC)
Communications interface points are not
insulated
[Heater snapping wire alarm] (KP2000 only)
Measurement scope: 10 to 100AAC (50/60Hz)
Accuracy rating: ±5.0%FS±1digit
CT input range : 0 to 125mA AC(50/60Hz)
Measurement category : None
Specified CT: LTA-P208
(hole diameter 12mm, sold separately)
(manufactured by URD, model : CTL-12-S36-8)
[Output 2] (Excluding KP3000)
Control cycle: Approximately 0.1 seconds
Output format: ON-OFF pulse type, current output type,
voltage output type, SSR drive pulse type and
arbitrary combination is possible
Control system: PID system, SPLIT system
Insulation: Internal circuit is insulated
(More than 20MΩ or more and 500VDC)
Outputs are not insulated
(Only ON-OFF pulse type is insulated)
[External signal input]
Number of outputs: (KP1000) Maximum 9 points
(KP2000/3000) Maximum 20 points
Input signal: No-voltage contact, open-collector signal
External contact
point capacity: 5VDC･2mA
Function: RUN/STOP
ADV
RESET
WAIT
(KP2000/3000) FAST
Pattern No. selection
(KP1000) (5 points of PTN1/PTN2/PTN4/PTN8/PTN10)
(KP2000/3000) (6 points ofPTN1/PTN2/PTN4/PTN8/PTN10/PTN20)
(The following functions are KP2000 only)
Manual output operation/Automatic output operation
(2 points of MAN1/AUTO1 and MAN2/AUTO2)
Preset manual/automatic output operation
Cancel alarm output
PV HOLD
Start/Reset timer
(4 points of TIMER1/TIMER2/TIMER3/TIMER4)
Insulation: Internal circuit is insulated
(More than 20MΩ or m
ore and 5
00VDC)
External input points are not insulated
[External signal output]
Output points: (KP1000) Maximum 9 points
(KP2000/3000) Maximum 20 points
Output signal: No voltage contact point, open collector output
External contact
point capacity: 24VDC･50mA
Function: Time signal
(KP1000) (5 points of PTN1/PTN2/PTN4/PTN8/PTN10)
(KP2000/3000) (8 points of TS1/TS2/TS3/TS4/TS5/TS6/TS7/TS8)
RUN/STOP
ADV
RESET
WAIT
END
Insulation: Internal circuit is insulated
(More than 20MΩ or more and 500VDC)
External signal output points are not insulated
[Panel sealing]
Corresponding to IEC60529 IP54
(Not possible during closed instrumentation)
[Terminal cover]
Code: RZ-TC1
Cover the terminals for safe.
About disposal of Electrical and Electronic Equipment
This product is subject to the WEEE Directive.
When disposing of the product, please separate
and collect it properly for reuse and recycling.
