Chino KP1000 User Manual

E22
Some items are not to be displayed depending on the model code and with
or without options.
Setting Item Setting range
Default
value
M
O
D
E
0
Executing SV
and time
(for KP1000)
SV Measurement scope, linear scale 0000.0
Time 000:00 to 999:59 000:00
Executing SV
and time
(for KP2000)
SV SV range 0000.0
Time 000:00 to 999:59 000:00
Executing PID
P
000.0 to 999.9 (0 is two-position
control)
005.0%
I 0000 to 9999 (0 is ∞) 0060s
D 0000 to 9999 (0 is OFF) 0030s
Executing second
output PID
P 000.0 to 999.9 005.0%
I 0000 to 9999 (0 is ∞) 0060s
D 0000 to 9999 (0 is OFF) 0030s
Executing alarm
1 and alarm 2
AL1
-1999.9 to 3000.0
*CT : 5.0 to 100.0
*TIMER : 0 to 3000.0
3000.0
AL2 -1999.9
Executing alarm
3 and alarm 4
AL3 3000.0
AL4 -1999.9
Executing
output limiter
(or Output
scaling)
L -05.0 to 100.0 000.0%
H 000.0 to 105.0 100.0%
Executing output
variation limiter
UP 000.1 to 100.0 100.0%
DOWN -100.0 to -000.1 -100.0%
Executing output preset
(KP2000 only)
-100.0 to 100.0 050.0%
Executing sensor
correction
-199.99 to 200.00 0000.0
Executing A.R.W.
(KP2000 only)
Ｌ
-100.0 to 000.0 -050.0%
Ｈ
000.0 to 100.0 050.0%
Executing subsidiary
output
(KP2000 only)
000.0 to 100.0 000.0%
SV correction
(KP2000 only)
-199.99 to 200.00 0000.0
M
O
D
E
1
Run operation key lock UNLOCK
､
LOCK UNLOCK
Cancel alarm output NON
､
RESET NON
Auto tuning
(for KP1000)
END
､
AT1
､
AT2
､
AT3 END
Auto tuning
(for KP2000)
END
､
AT1
､
AT2
､
AT3
､
AT4 END
Program drive system
(for KP1000)
MASTER KEY, MASTER EXT
SLAVE EXT, MASTER COM
MASTER
KEY
Program drive system
(for KP2000)
MASTER KEY
､
MASTER EXT
SLAVE EXT, MASTER COM
MASTER FREE
MASTER
KEY
Pattern selection system
(for KP1000)
KEY, EXT, COM KEY
Pattern selection system
(for KP2000)
KEY
､
EXT
､
COM
､
FREE KEY
Time display system PASS STEP
､
PASS PATTERN PASS STEP
Control format REMAIN STEP PROGRAM
PV Hold
(KP2000 only)
NON
､
HOLD NON
Operation during
power supply
(KP2000 only)
CONTINUE
､
RESET CONTINUE
Existence of CT screen
(KP2000 only)
NON
､
DISPLAY
ＮＯＮ
M
O
D
E
2
Pattern No.
(for KP1000)
1 to 19 1
Pattern No.
(for KP2000)
1 to 30 1
Step No. 0 to 30 0
SV(for KP1000) Measurement scope, linear scale 0.0
SV(for KP2000) SV range 0.0
Timer 000 : 00 to 999 : 59 000 : 00
SV range
(KP2000 only)
-1999.9 to 3000.0
-200.0 to
1370.0
Pattern repeat 0000 to 9999 0000
Pattern clear
(for KP1000)
EACH (01 to 19), ALL END
Setting Item Setting range
Default
value
M
O
D
E
2
Pattern clear
(for KP2000)
EACH (01 to 30)
､
ALL END
Pattern copy
(for KP1000)
PTN:
（
01 to 19
）→（
01 to 19
）
, YES END
Pattern copy
(for KP2000)
PTN: (01 to 30)
→
(01 to 30)
､
YES END
Program reset SV
(for KP1000)
Measurement scope, linear scale 0000.0
Program reset SV
(for KP2000)
SV range 0000.0
Time unit HOUR:MIN, MIN:SEC HOUR:MIN
M
O
D
E
3
PID
16 types
P 000.0 to 999.9 005.0%
I 0000 to 9999 (0 is
∞
) 0060s
D 0000 to 9999 (0 is OFF) 0030s
A.R.W.
(for KP1000)
L -100.0 to 000.0 -050.0%
H 000.0 to 100.0 050.0%
A.R.W. 8 types
(for KP2000)
L -100.0 to 000.0 -050.0%
H 000.0 to 100.0 050.0%
Second output
PID
P
000.0 to 999.9 (0 is two-position
control)
005.0%
I 0000 to 9999 (0 is
∞
) 0060s
D 0000 to 9999 (0 is OFF) 0030s
Second output gap
-100.0 to 100.0 000.0%
Output dead
band
PID 0.0 to 9.9 0.0%
P=0 0.1 to 9.9 0.5%
Second output
dead band
PID 0.0 to 9.9 0.0%
P=0 0.1 to 9.9 0.5%
Alarm format
(for KP1000)
AL1
DH, DL
DHW, DLW
AH, AL
AHW, ALW
DH
AL2 DL
AL3 DH
AL4 DL
Alarm format of
alarm 1
and alarm 2
(for KP2000)
AL1
PV, DV, ADV, SV, MV (MV1, MV2)
H, HW, HK, HWK
L, LW, LK, LWK
CT, TIMER, WAIT, FAIL
DV-H
AL2 DV-L
Alarm format of
alarm 3
and alarm 4
(for KP2000)
AL3 DV-H
AL4 DV-L
Alarm 1 and
Alarm 2
8 types
AL1
-1999.9 to 3000.0
*CT: 5.0 to 100.0
*TIMER: 0 to 30000
３０００．０
AL2
－１９９９．９
Alarm 3 and
Alarm 4
8 types
AL3
３０００．０
AL4
－１９９９．９
Alarm dead band
AL1
000.00 to 200.00
002.00
AL2 002.00
AL3 002.00
AL4 002.00
Alarm delay 0000.0 to 2000.0 0000.0s
SV 8 types for
AT2
Run ON
､
OFF
Only No.1 is
ON
SV -19999 to 30000
Automatic
development
SV section for
automatic PID
Measurement scope, linear scale
Automatic
development
SV 8 types for
AT3
Run ON
､
OFF OFF
SV
Auto PID switch
between SV
Automatic
development
AT2, AT3 start direction UP
､
DOWN UP
Control algorithm POSITION
､
VELOCITY POSITION
M
O
D
E
4
Output limiter
8 types
(or Output
scaling)
L -05.0 to 100.0 000.0%
H 000.0 to 105.0 100.0%
Second output
limiter
(or Second
output scaling)
L -05.0 to 100.0 000.0%
H 000.0 to 105.0 100.0%
Output variation
limiter 8 types
UP 000.1 to 100.0 100.0%
DOWN -100.0 to -000.1 -100.0%
KP1000 / KP2000 List of Parameters
