E23
Setting Item Setting range
Default
value
M
O
D
E
4
Second output
variation limiter
UP 000.1 to 100.0 100.0%
DOWN -100.0 to -000.1 -100.0%
Program end
output
OUT1 CONTROL, -005.0 to 105.0 CONTROL
OUT2 CONTROL, -005.0 to 105.0 CONTROL
Output preset
(for KP1000)
-100.0 to 100.0 050.0%
Output preset 8 types
(for KP2000)
-100.0 to 100.0 050.0%
Pulse cycle
(or Second output)
001 to 180 030s
FB tuning END
､
START END
FB zero span
Z 00.0 to 99.9 00.0%
S 000.1 to 100.0 100.0%
FB dead band 0.5 to 5.0 2.0%
PV abnormal
output
OVR
-05.0 to 105.0
000.0%
UDR 000.0%
PV abnormal
second output
OVR
-05.0 to 105.0
000.0%
UDR 000.0%
Direct/Reverse control
(KP2000 only)
DIRECT
､
REVERSE REVERSE
Direct/Reverse control for
output 2
(KP2000 only)
DIRECT
､
REVERSE DIRECT
Preset manual
(KP2000 only)
-005.0 to 105.0 000.0%
Second output preset
manual
(KP2000 only)
-005.0 to 105.0 000.0%
Second output control
system
(KP2000 only)
PID
､
SPLIT PID
SPLIT
(KP2000 only)
DIR 00.0 to 60.0 0.0%
REV 40.0 to 100.0 100.0%
M
O
D
E
5
Measurement
range
Universal
See 'Measurement range list' K1
4-wire
resistance
thermometer
See 'Measurement range list' Pt100Ω1
RJ INT, EXT INT
Unit
°
C,K
°
C
Measurement scope Scale scope of measurement range
-200.0 to
1370.0
Linear scale
DOT
Scale
0 to 4 1
-1999.9 to 3000.0
0000.0 to
2000.0
Sensor correction 8 types -199.99 to 200.00 0.00
PV decimal point 0 to 4 1
Digital filter 00.0 to 99.9 00.1s
SV decimal point for
display
0 to 4 1
M
O
D
E
6
Time signal 8 types
ON
000:00 to 999:59
000:00
OFF 001:00
Real temperature
compensation 8 types
0000.1 to 2000.0
2000.0
Waiting time alarm 8 types 000:00 to 999:59 001:00
M
O
D
E
7
Transmission type
(for KP1000)
PV, SV, MV (MV1, MV2), MFB PV
Transmission scale
(for KP1000)
-1999.9 to 3000.0
-0200.0 to
1370.0
Transmission type
(KP2000
High-performance type)
PV
､
SV
､
MV(MV1
､
MV2)
､
MFB
､
SUB PV
Transmission scale
(KP2000
High-performance type)
-1999.9 to 3000.0
-0200.0 to
1370.0
Transmission type
(KP2000 Normal type)
PV
､
SV
､
MV(MV1
､
MV2)
､
MFB
､
SUB PV
Transmission scale
(KP2000 Normal type)
-1999.9 to 3000.0
-0200.0 to
1370.0
Subsidiary output 8 types
(KP2000 only)
000.0 to 100.0 0.0
Setting Item Setting range
Default
value
M
O
D
E
8
Communication speed 2400
､
4800
､
9600
､
19200
､
38400 9600bps
Instrument number 01 to 99 01
Communications function
(KP2000 only)
COM
､
TRANS COM
Communications
transmission type
(for KP1000)
PV
､
SV
､
MV(MV1
､
MV2)
､
MFB PV
Communications
transmission type
(for KP2000)
PV
､
SV
､
MV(MV1
､
MV2)
､
MFB
､
SUB PV
Communications protocol
MODBUS(RTU)
､
MODBUS(ASCII)
､
PRIVATE
MODBUS
(RTU)
Communications character
7BIT/EVEN/STOP1
- - -
8BIT/ODD/STOP2
8BIT/NON/
STOP1
Select communications
2 port function
(KP2000 only)
COM
､
ENG
ENG
Communications speed
for COM2
(KP2000 only)
2400
､
4800
､
9600
､
19200
､
38400 9600bps
Instrument number for COM2
(KP2000 only)
01 to 99 01
Communications function
for COM2
(KP2000 only)
COM
､
TRANS COM
Communications
transmission type for COM2
(KP2000 only)
PV
､
SV
､
MV(MV1
､
MV2)
､
MFB
､
SUB PV
Communications protocol
for COM2
(KP2000 only)
MODBUS(RTU)
､
MODBUS(ASCII)
､
PRIVATE
MODBUS
(RTU)
Communications character
for COM2
(KP2000 only)
7BIT/EVEN/STOP1
- - -
8BIT/ODD/STOP2
8BIT/NON/
STOP1
M
O
D
E
1
1
Display backlight GREEN
､
ORANGE
､
AUTO AUTO
Display contrast 000 to 100 050%
Key backlight AUTO
､
OFF
､
ON AUTO
External signal layout
(KP2000 only)
See 'External signal input' No allocation
Testing alarm output
(KP2000 only)
OFF, AL1, AL2, AL3, AL4 OFF
Testing timer signal output
(KP2000 only)
No. 0 to 8 (0 is output OFF) No. 0
Testing status output
(KP2000 only)
OFF, RUN/STOP, ADVANCE
RESET, WAIT, END
OFF
M
O
D
E
1
2
(KP2000 only)
Measurement range
zero correction
-19.999 to 20.000 00.000
Measurement range
span correction
0.9000 to 1.1000 1.0000
Output 2 zero correction -10.000 to 10.000 00.000
Output 1 span correction 0.9000 to 1.1000 1.0000
Output 1 zero correction -10.000 to 10.000 00.000
Output 2 span correction 0.9000 to 1.1000 1.0000
Transmission output
(High-performance type)
zero correction
-10.000 to 10.000 00.000
Transmission output
(High-performance type)
span correction
0.9000 to 1.1000 1.0000
Transmission output
(Normal type)
zero correction
-10.000 to 10.000 00.000
Transmission output
(Normal type)
span correction
0.9000 to 1.1000 1.0000
CT input zero correction -10.000 to 10.000 00.000
CT input span correction 0.9000 to 1.1000 1.0000
