CHINT NR2 Series - Page 4

02
Table 3 Combination with contactor and fuse
Rated operating voltage Ue
Rated impulse withstand voltage Uimp
690V
6kV
5A
220V/2.73A ; 380V/1.58A
220V 0.2A
1NO 1NC
6A
Model
NR2-
11.5
NR2-
25
NR2-
36
NR2-
93
NR2-
150
NR2-
200
NR2-
630
Auxiliary circuit
Ith
AC-15
DC-13
Auxiliary contact type
Specification of
matching fuse A
NR2-11.5
Model
Setting
current
range A
Specification of
matching fuse gG
(Recommend RT16) A
Recommended
matching
contactor
Sectional area
of connecting
wire mm²
0.1~0.16
0.16~0.25
0.25~0.4
0.4~0.63
0.63~1
1~1.6
1.25~2
1.6~2.5
2.5~4
4~6
5.5~8
7~10
9~13
2
2
2
2
4
4
6
6
10
16
20
20
25
1.5
2.5
NC6-09
1
Table 2 (continued)
