CHINT NXR-12 - Page 9

07
2) Operation and commissioning
Figure 5 Operation diagram
NO
NC
98 97 96 95
2/ T1 4 /T2 6 /T3
2/T1 4/T 2 6/T3
1/ L1 3 /L2 5/ L3
A
A
A
Stop
Reset
Test
Operation indication
adjustable current range
Automatic reset
Manual reset
M3.5
1.2 N.m
M4
1.7 N.m
M10
10 N.m
2
S (mm )
NXR-100
NXR-38
NXR-25
NXR-12
4～35
4～10
1～6
1～4
4～35
A＞4mm,
L＜12mm
A＞4mm,
L＜10mm
A＞3.5mm,
L＜9mm
4～10 4～10 4～10
1～6 1～6 1～6 1～6 1～6
1～4 1～4 1～4 1～4 1～4
M3.5
0.8 N.m
2
mm
2
mm
2
mm
2
mm
2
mm
2
mm
NXR-12～
100
1～2.5
A＞3.5mm,
L＜8mm
Main
circuit
Auxiliary
circuit
1～2.5 1～2.5 1～2.5 1～2.5 1～2.5
Table 5 Wiring parameters
