ASSEMBLY
ASSEMBLY INSTRUCTIONS
1. ASSEMBLY OF FRONT WHEEL TO THE FRONT TUBE OF THE FRAME.
2. ASSEMBLY OF THE HANDLEBAR TO THE FORK TUBE.
3. ASSEMBLY OF PARKING DEVICE.
4. ASSEMBLY OF REAR AXLE.
5. ASSEMBLY OF REAR WHEELS.
6. ASSEMBLY OF PUSH HANDLE TO THE FRAME.
Assemble the two parts of the push handle, so that the pins are showing through the handle openings.
6-1 – Insert the handle to the frame
6-2 – Press the red lever down to quickly remove the handle.
7. PUTTING THE BAG ON THE PUSH HANDLE.
8. FIXING THE SEAT TO THE FRAME.
Puttheseatandxitwithplasticwashers.
9. ASSEMBLY OF SAFETY BUMPER TO THE SEAT.
10. ASSEMBLY OF FABRIC COVER TO THE SAFETY BUMPER.
Note: Put the lower part of the fabric cover over the safety bumper and close the bumper.
11. ASSEMBLY OF HEAD REST TO THE CANOPY.
12. ASSEMBLY OF CANOPY TO THE BACKREST.
13. ASSEMBLY OF REAR BASKET TO THE FRAME.
Fixthebasketwithscrews.
14. ASSEMBLY OF GUIDING AXLE.
Putthefrontendoftheguidingaxletotheforkandtherearendxtothelowertubeusingwashers.
15. ASSEMBLY OF MUD GUARDS.
IMPORTANT!Followexactlytheinstructionsgivenandcheckthepictures.Keepyourhandsfrom
entrapment!
IMPORTANT! After each operation, make sure that you have followed the instructions correctly and
thexingisstable!
CAUTION!Makesureallxingsaretightbutnotovertightenthem.Ifsomepartsareloosethiscould
cause disintegration of the tricycle and injury to your child.
