4
Necessary tools: For TOY’s assembly no tools are needed!
ASSEMBLY INSTRUCTIONS
IMPORTANT! Follow exactly the instructions given and check the pictures.
IMPORTANT! AFTER EACH OPERATION, MAKE SURE THAT YOU HAVE FOLLOWED THE
INSTRUCTIONS CORRECTLY AND THE FIXING IS STABLE!
IMPORTANT! Tighten the screws well, without overtightening them. If screws are loose, this could
lead to disassembly of some part and injure to the child!
ASSEMBLY AND FUNCTIONS
1. INSTALLING THE FRONT WHEEL AND FORK TO THE FRONT WHEEL
1-1 – Insert the connecting elements at both sides of the front wheel.
1-2 – Place the fork to the tubes of connecting elements. Press the pins and insert the tubes of connect-
ing elements until you hear a click sound and pins show from the openings.
1-3 – Insert the pedals at both sides.
1-4 – Motion of wheels and pedals mode.
After assembly, the front wheel and pedals move together (1).
Press the button to change the motion of front wheel and pull the pedal outwards – the front wheel mo-
tion will stop, but pedal will continue to move (2).
Press again the button and pull the pedal outwards – you can now remove the pedal from the wheel.
2. INSTALLING THE FORK TO THE FRONT WHEEL
Align the fork to the tube of front wheel. Press the pins at the fork and insert it into the tubes of front
wheel until you hear a click sound and buttons show from the openings.
3. INSTALLING THE SEAT BASE
AligntheseatbasetotheframeandxwiththescrewwithplasticheadA.
4. INSTALLING AND REMOVING OF REAR WHEELS
Place each of the parking device to the rear tube of the frame and align with the tube’s opening.
Inserteachoftherearwheelaxisintotheopeningsatbothsidesofthereartubeandcwithscrewsas
gureshows(viewB).
Note:Makesurethatwheelsarestablexedastrytopullthemoutwards.
To remove the rear wheels, rst untighten and remove the screws and then press the buttons for
removalandtakethewheelso󰀨theframe.
5. INSTALLING THE FRONT WHEEL
Place the fender onto the tube of front fork.
Insertthetubeoftheforkintotheopeningatfrontpartoftheframeandpresstox.
ATTENTION!Byassembly,thepinoftheforktubemustpointoutwardsasgureshows.
