9.4 Antennas
9.4.1 GPS antennas
Active GPS antenna
Instrument: PQ25, PQ35 and PQ45.
Part number: 1AGPSANTM (M for magnetic
mount).
Input DC voltage: 2.5V-12V.
DC current: 11mA-13mA.
Operating frequency range: 1.575.42MHz.
Weight: 100g.
Cable length: 3m.
Figure 9.4.1.1
9.4.2 Cellular antennas
T-bar penta-band cellular antenna
Instrument: PQ25, PQ35 and PQ45.
Part number: TBA.
Cellular technologies: GSM / CDMA / PCS
/ DCS / UMTS / WCDMA.
IP rating: IP67 (waterproof).
Dimensions (L x W x H) mm: 105.7 x 14 x
6.5.
Weight: 40g.
Figure 9.4.2.1
Instrument: PQ25, PQ35 and PQ45.
Description: 3G Antenna
Part number: 1A3GANT
Description: 4G Antenna
Part number: 1A4GANT
9.4.3 Combined GPS + Cellular antennas
Instrument: PQ25, PQ35 and PQ45.
Description: GPS / 3G Antenna
Part number: 1AGPS3GANT
Description: GPS / 4G Antenna
Part number: 1AGPS4GANT
