CHMER WIRE EDM QUICK START
INDEX
CHAPTER 1. START UP OF OPERATION-------------------------------------------- 1
1.1 Booting Up Procedures------------------------------------------------------ 1
1.2 BASIC ACCESSORIES---------------------------------------------------- 3
1.3 PRE-MACHINING SETUP------------------------------------------------ 7
CHAPTER 2.
---------------------------------------------------------------------------------- 15
2.1 FILE MANAGEMENT & GRAPH SIMULATION-------------------- 15
CHAPTER 3.
SETUP FOR CUTTING--------------------------------------------------- 25
3.1 Set Z axis height-------------------------------------------------------------- 25
3.2 Call up a job file for simulation-------------------------------------------- 26
3.3 MEM DATA Set-------------------------------------------------------------- 26
3.4 Call up cutting technology---------------------------------------------------
28
3.5 Reset Local Coordinate------------------------------------------------------
28
CHAPTER 4.
WIRE POSITIONING FUNCTIONS---------------------------------- 29
4.1 Edge Find---------------------------------------------------------------------- 29
4.2 Find Slot Center-------------------------------------------------------------- 30
4.3 Find Hole Center------------------------------------------------------------- 31
4.4 Angle Rotation (AR)--------------------------------------------------------- 32
4.5 Find Board Center (BOARD CP.)------------------------------------------ 32
4.6 MDI. MOVE------------------------------------------------------------------ 35
4.7 CYLIND C.P (Find Cylinder Center)------------------------------------- 36
4.8
CORNER MOVE（find corner position）--------------------------------
37
4.9
MEM ZOOM（MEMF10）---------------------------------------------
38
CHAPTER 5.
F.A.Q. & TROUBLE SHOOT-------------------------------------------- 39
