Choice Select IR-320 - Installation and Operation Guide; Receiver Setup with Extender Probe; Receiver Setup without Extender Probe

Installation & Operation Guide
Receiver
Picture 1 Picture 2
Picture 3 Picture 4
Working with extender probe
Working without
extender probe
Working without extender probe
Make sure the IR probe is affixed toward
IR sensor receiving Window with proper position
(within 0.5M and working angles +/- 15°).
Keep Vertical
Power
Adaptor
(Using IR )
Antenna
Not less than 0.3M and not more than 5M
Working Angle not more than +/- 15°
Working Angle not more than +/-
15°
Side View
7.6 M
8 M
0.4
