Chroma 69225 Series User Manual

Installation
2-3
2
Temperature
sensor
Temperature sensing board
3
Temperature
communication
parallel line
Temperature sensor parallel
communication wire
4
Temperature
communication
line
Temperature sensing board is
for connecting 692 series
communication wire.
5
Silicone band
+ ladder lock
The silicone band and ladder
lock are for fixing temperature
sensing board on surface of
battery.
6 Driver wire
The output wire is for
connecting output terminal and
DUT (battery).
7 V-sense wire
The Remote Sense wire is for
connecting output terminal of
RMT Sense and DUT (battery).
