26 Chromalox 3101 Operator's Manual
Custom Scaling Page
MENU Description Available Settings Security
DP Analog Input Decimal Pts. 0 = none C
1 = 123.4
2 = 12.34
3 = 1.234
AINL Analog Process Input Low -500 to 5000
AINH Analog Process Input High -500 to 5000
AOTL Analog Process Output Low Instrument Sensor Span
AOTH Analog Process Output High Instrument Sensor Span
This PAGE appears only when Analog
Input is selected, Remote SP is enabled,
or Analog Output is enabled on SET PAGE.
SCAL
PAGE
▲▼
RESET
AL 1
PAGE
▲▼
RESET
Alarm #1 Page
MENU Description Available Settings Security
EN 1 Alarm 1 Enable OFF = Disabled C
ON = Enabled
TYP1 Alarm 1 Type NONE = Disabled (off)
HI = High Alarm
LO = Low Alarm
HILO = High-Low Alarm
PDE = Plus Deviation Alarm
-DE = Minus Deviation Alm
DE = Plus/Minus Dev Alm
RLY1 Alarm 1 Relay NDE = normally de-energized
non-latching
NE = normally energized
non-latching
NDEL = normally de-energized
latching
NEL = normally energized
latching
ALO1 Alarm 1 Low Setpoint Instrument Sensor Span
AHI1 Alarm 1 High Setpoint Instrument Sensor Span
DB1 Output 1 Dead Band 0 to 100°F
(Alarm Hysteresis) (.00 to 6.25% of span for
analog inputs)
INH1 Alarm 1 Inhibit OFF
ON
VIEW
DATA
VIEW
DATA
9
9
9
44
44
36
12
