Chromalox 3101 User Manual

Chromalox 3101 Operator's Manual 27
AL 2
PAGE
▲▼
RESET
Alarm #2 Page
MENU Description Available Settings Security
EN 2 Alarm 2 Enable OFF = Disabled C
ON = Enabled
TYP2 Alarm 2 Type NONE = Disabled (off)
HI = High Alarm
LO = Low Alarm
HILO = High-Low Alarm
PDE = Plus Deviation Alarm
-DE = Minus Deviation Alm
DE = Plus/Minus Dev Alm
RLY2 Alarm 2 Relay NDE = normally de-energized
non-latching
NE = normally energized
non-latching
NDEL = normally de-energized
latching
NEL = normally energized
latching
ALO2 Alarm 2 Low Setpoint Instrument Sensor Span
AHI2 Alarm 2 High Setpoint Instrument Sensor Span
DB2 Output 2 Dead Band 0 to 100°F
(Alarm Hysteresis) (.00 to 6.25% of span for
analog inputs)
INH2 Alarm 2 Inhibit OFF
ON
VIEW
DATA
36
12

Chromalox 3101 Specifications

General

Brand	Chromalox
Model	3101
Category	Controller
Language	English
