Chromalox 3101 Operator's Manual 67
Display Page
See page 24 for details.
Display Page
MENU Description Displays Security
PROC Process Variable Sensor Span A
L SP Limit Setpoint Sensor Span
LOUT Limit Output 0.0 TO 100.0%
TOSP Time Over Setpoint 0 TO 999.9 MIN
PEAH Peak Temperature Instrument Sensor Span
ALR Alarm Output Status NONE = No alarms
AL 1 = Alarm #1
AL 2 = Alarm #2
AL12 = Alarm #1 and #2
Setup Page
See page 24 for details.
SET Page
MENU Description Displays Factory Setting Security
LOCH Security Lock 0 to 9999 458 A
L SP Limit Setpoint Instrument Sensor Span Span High C
DB Limit Dead Band 0 to 100 1°F
ENTI Event Input Function NONE = Disabled ARST D
ARST = Alarm Reset
AOUT Analog Output Enable NONE = Disabled NONE
PROC = Process Variable
CONT Controller Type HI HI
LO
CODE User Security Code 0 to 999 0
0-122 = Security level A
123-457 = Security level B
458-735 = Security level C
736-999 = Security level D
ALO Ambient Temp Low -3 to 153 65
AHI Ambient Temp High -3 to 153 85
LDSP Lower Display ON = Enabled ON
Enable OFF = Disabled
