68 Chromalox 3101 Operator's Manual
Input Page
MENU Description Available Settings Factory Setting Security
SENS Sensor Type Sensor Type selected here must J C
agree with dip switch settings.
J = J Thermocouple
K = K Thermocouple
T = T Thermocouple
E = E Thermocouple
R = R Thermocouple
S = S Thermocouple
B = B Thermocouple
RTD = 100 Pt RTD
(α = .00385)
4-20 = 4 to 20mA
0-5 = 0 to 5 Vdc
1-5 = 1 to 5 Vdc
UNIT Display Units NONE = none (analog inputs) °F
°F = Degrees Fahrenheit
°C = Degrees Celsius
COFF Calibration Offset 0 to ±100°F 0
(±6.25% of span for analog inputs)
SPLL Setpoint Low Limit Instrument Sensor Span Span Low
SPUL Setpoint Upper Limit Instrument Sensor Span Span High
CALS Sensor Calibration INLO = Input low INLO D
INHI = Input high
DONE = Calibration fi nished
AO 0 Analog Output Zero 0 to 4095 781
Calibration
AO S Analog Output Span 0 to 4095 3902
RECC Factory Calibration RDY = Ready RDY
Recovery ---- = Wait
DONE = Finished
See page 25 for details.
Input Page
