Chromalox 3101 Operator's Manual 69
Custom Scaling
Page
See page 26 for details.
Custom Scaling Page
MENU Description Available Settings Factory Setting Security
DP Analog Input Decimal Pts. 0 = none 1 C
1 = 123.4
2 = 12.34
3 = 1.234
AINL Analog Process Input Low -500 to 5000 0.0
AINH Analog Process Input High -500 to 5000 100.0
AOTL Analog Process Output Low Instrument Sensor Span Span Low
AOTH Analog Process Output High Instrument Sensor Span Span High
Alarm #1 Page
See page 26 for details.
Alarm #1 Page
MENU Description Available Settings Factory Setting Security
EN 1 Alarm 1 Enable OFF = Disabled OFF C
ON = Enabled
TYP1 Alarm 1 Type NONE = Disabled (off) NONE
HI = High Alarm
LO = Low Alarm
HILO = High-Low Alarm
PDE = Plus Deviation Alarm
-DE = Minus Deviation Alm
DE = Plus/Minus Dev Alm
RLY1 Alarm 1 Relay NDE = normally de-energized NDE
non-latching
NE = normally energized
non-latching
NDEL = normally de-energized
latching
NEL = normally energized
latching
ALO1 Alarm 1 Low Setpoint Instrument Sensor Span Span Low
AHI1 Alarm 1 High Setpoint Instrument Sensor Span Span High
DB1 Output 1 Dead Band 0 to 100°F 1°F
(Alarm Hysteresis) (.00 to 6.25% of span for
analog inputs)
INH1 Alarm 1 Inhibit OFF OFF
ON
