Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
1 — 15 Amp
Blue
Washer Motor
2 — 25 Amp
Natural
Powertrain Control
Module (PCM)
3 — 25 Amp
Natural
Ignition Run/Start
4 — 25 Amp
Natural
Alternator
5 ———
6 — 25 Amp
Natural
Ignition Coils/Injectors
7 ———
8 — 30 Amp
Green
Starter
9 ———
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
10 30 Amp
Pink
— Windshield Wiper
11 30 Amp
Pink
— Anti-Lock Brake System
(ABS) Valves
12 40 Amp
Green
— Radiator Fan
13 50 Amp
Red
— Anti-Lock Brake System
(ABS) Pump Motor
14———
15 50 Amp
Red
— Radiator Fan
16———
17———
18———
19———
7
MAINTAINING YOUR VEHICLE 399
