Chrysler Crossfire 2007 - Page 255

Underhood Accessory Fuse Block Fuses
Cavity Fuse Circuits
1 5 Amp
Beige
Garage Door Opening Signal,
Tire Pressure Control and Seat
Heater
2 5 Amp
Beige
Control Unit Airbag
3 5 Amp
Beige
Indicator, Safety Restraint System
and Indicator Passenger Airbag
Off
4 7.5 Amp
Brown
Heated Mirror
5 15 Amp
Blue
Radio (Coupe)
5 25 Amp
White
Roof Control Module (Roadster)
6 5 Amp
Beige
Exterior Mirror Adjustment, Left
And Right (Coupe)
6 40 Amp
Orange
Roof Hydraulic Unit (Roadster)
7 5 Amp
Beige
Occupation Classification Module
(Right Seat)
Cavity Fuse Circuits
8 15 Amp
Blue
Radio
9 5 Amp
Beige
Control Unit Airbag
10 5 Amp
Beige
Speed Control
11 15 Amp
Blue
Ignition Coil 6 Cyl.
12 10 Amp
Red
Washer Liquid Heater, Washer
Nozzle Heater
13 10 Amp
Red
Roof Light, Horn, Anti-Theft-
Alarm, Trunk Light and Tire
Pressure Control
14 10 Amp
Red
Diagnostic Socket
15 5 Amp
Beige
Climate Control, Auxiliary Water
Pump
16 10 Amp
Red
Spoiler Motor
17 40 Amp
Orange
Electronic Stability Program
MAINTAINING YOUR VEHICLE 255
7
