IN CASE OF EMERGENCY 281
Tire Service Kit Storage
Tire Service Kit Location — If Equipped
Tire Service Kit And Emergency Fuel Funnel
The Tire Service Kit is secured with a strap and is
stored under the load floor within the second row.
Tire Service Kit Location — If Equipped
Tire Service Kit And Components And Operation
Tire Service Kit Components
Using The Mode Select Knob And Hoses
Your Tire Service Kit is equipped with the following
symbols to indicate the air or sealant mode.
Selecting Air Mode
Push in the Mode Select Knob and
turn to this position for air pump oper-
ation only.
Selecting Sealant Mode
Push in the Mode Select Knob and
turn to this position to inject the Tire
Service Kit Sealant and to inflate the
tire.
1 — Tire Service Kit
2 — Refueling Funnel
1 — Sealant/Air Hose
2 — Hose Accessories
3 — Mode Select Knob
4 — Pressure Gauge
5 — Deflation Button
6 — Power Switch
7 — Sealant Bottle
8 — Power Plug
7
