SERVICING AND MAINTENANCE 319
F78 – 15 Amp Blue TCM (ZF) / E-Shifter / Cluster
F79 – 10 Amp Red ICS / HVAC / SCCM/ EPB SW
F80 – – Not Populated
F81 – – Not Populated
F82 – – Not Populated
F83
20 Amp Blue – TT Park Lights *
30 Amp Pink – Headlamp Washer Pump *
F84 30 Amp Pink – Drive Train Control MOD *
F85 – 20 Amp Yellow Cigar Lighter
F86 – – Not Populated
F87 – – Not Populated
F88 – 20 Amp Yellow Front Heated Seats *
F89 – 20 Amp Yellow Rear Heated Seats *
F90 – – Not Populated
F91 – 15 Amp Blue
Front Ventilated Seats/Heated
Steering Wheel *
F92 – 5 Amp Tan Security Gateway
F93 – – Not Populated
F94 40 Amp Green – ESC Motor Pump
F95A – 10 Amp Red USB Charge Port — ACC/RUN
Cavity Cartridge Fuse Blade Fuse Description
*If Equipped
