18
Installation
Required tools & material:
» 2 x shift cable index housing with end caps on both sides
» 2 x wire end caps
» 3mm Allen key
» grease
» side cutter / cable cutter
1. Mount the levers on your handle bar in your ergonomically preferred
position. Fasten the hex screws with a maximum clamping torque of
2,5 Nm. Also pay attention to information on installation and clamping
torque provided by your handle bar manufacturer.
2. Mount the shiftbox onto the hub´s hexagonal interface bolt. The hub´s
gear position has no significance. Apply a small amount of grease onto
the hub´s shifting shaft to ensure easy sliding between shaft and the
shiftbox interface during installation.
2,5 Nm
