cabinets with connections at the bottom) or the screws in the upper front cover (in cabinets with con-
nections at the top) Figure 17.
30
Cabinet with connections at the bottom - Cabinet with connections at the top
Figure 17: Screws (SVGm-3WF-xxC-480 and SVGm-4WF-xxC-400 models).
Protectores de sobretensión
Surge voltage protection
Figure 18: Screws ( SVGm-3WF-xxxC-690 and SVGm-4WF-xxxC-550 models).
The green indicator voltage protection indicate that they are working correctly. Im-
mediately replace those whose indicator is red, see “10.8.- MAINTENANCE OF SURGE
PROTECTIVE DEVICES: SVGm-3WF-xxxC-690 and SVGm-4WF-xxxC-550”
