176
SVGm
Instruction Manual
ENGLISH
7.9.- REMOTE CONTROL
Note: This screen is not visible on the “slave” devices.
Note: Feature available from HMI version 1.20 of the device.
The device can consult an external analyzer for the active and reactive power values to be compen-
sated. This option allows reactive power to be compensated without using the internal measurement
transformers.
The remote control option is activated and the analyzer is selected on this screen, Figure 67.
Figure 67: Configuration screen: Remote control.
Activate the Remote Control ☑ option to use an external analyzer.
Select the CIRCUTOR power analyzer or meter from the drop-down menu.
Note: The compensation in this mode of operation is slower. The reaction time is about 15 seconds.
Press the key to access the next configuration step
Press the key to access the main screen of the device without saving the configuration values.
