Ciro Mazzoni LOOP ANTENNA MIDI - Page 21

78
3. there are some
metallic structures
too close to the
antenna
4. the antenna is too
low above the
ground
3. reposition the
antenna
4. rise the antenna
(the right height
from a flat surface
is 1.5m)
S.W.R. is too high on
every band
1. the coaxial cable is
short-circuited
2. the coaxial
connectors aren’t
grounded
3. there are some
metallic structures
too close to the
antenna
1. check the cable
2. check the
connector on the
cable
3. reposition the
antenna
With a constant concern for improvement, Ciro Mazzoni Radiocomunicazioni reserves the right to modify the technical
specifications provided in their manual, at any time, at their discretion.
The updated manual is available for download on our website.
