• USB Type A connector
• USB mini-Type B (console) port
• LEDs
• Mode button
• Beacon LED (UID button)
All the switch models have similar components. See the following illustration for example.
The Catalyst 9300 switches might have slight cosmetic differences on the bezels.
Note
Figure 1: C9300-48P Switch Front Panel
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
3
Product Overview
Front Panel Components
