Configuring Quality of Service
Defining General Settings
ESW 500 Series Switches Administration Guide 306
12
STEP 1 Click Quality of Service > General > CoS to Queue. The
Cos to Queue Page
opens:
Cos to Queue Page
The
Cos to Queue Page
contains the following fields:
• Restore Defaults — Restores all queues to the default CoS settings. The
possible field values are:
- Checked — Restores all queues to the default CoS settings.
- Unchecked — Maintain the CoS settings currently defined.
• Class of Service — Specifies the CoS VLAN (CoS) priority tag values, where
zero is the lowest and 7 is the highest.
• Queue — Defines the traffic forwarding queue to which the CoS priority is
mapped. Four traffic priority queues are supported, where Queue 4 is the
highest and Queue 1 is the lowest.
STEP 2 Define the relevant mapping.
STEP 3 Click Apply. CoS to queues are mapped, and the device is updated.
