Cisco NCS 5000 Series Hardware Installation Guide

•
A management and console interface are on the port (front) side of the router whereas the USB interface
on the fan (back) side of the router.
Power Supply
The Cisco NCS 5001 chassis has slots for two 1+1 redundant power supplies. Power supply options need to
be configured with the base chassis. A minimum of one power supply is required for normal operation. The
following table lists the power supplies that are configurable with the Cisco NCS 5001 router.
Table 2: Power Supplies for the Cisco NCS 5001 router
Power SupplyPart Number
Cisco NCS 5000 Power DC 930W Front to Back AirflowNC5K-PDC-930W-FR
Cisco NCS 5000 Power DC 930W Front to Back Airflow, spareNC5K-PDC-930W-FR=
Cisco NCS 5000 Power DC 930W Back to Front AirflowNC5K-PDC-930W-BK
Cisco NCS 5000 Power DC 930W Back to Front Airflow, spareNC5K-PDC-930W-BK=
Cisco NCS 5000 Series Router Power AC 650W Front to Back AirflowNC5K-PAC-650W-FR
Cisco NCS 5000 Series Router Power AC 650W Front to Back
Airflow, spare
NC5K-PAC-650W-FR=
Cisco NCS 5000 Series Router Power AC 650W Back to Front AirflowNC5K-PAC-650W-BK
Cisco NCS 5000 Series Router Power AC 650W Back to Front
Airflow, spare
NC5K-PAC-650W-BK=
Fan Modules
The Cisco NCS 5001 chassis has slots for two 1+1 redundant fan modules. The fan modules are hot-swappable.
Fan modules operate in an 1+1 redundancy mode. Fan options need to be configured with the base chassis.
The Cisco NCS 5001 system supports both forward and reverse airflow. The system can work with a single
fan failure. More than one fan failure leads to system shutdown. The following table lists the fan modules
that are configurable with the Cisco NCS 5001 router.
Table 3: Fan Modules for the Cisco NCS 5001 router
Fan ModulePart Number
Cisco NCS 5001 Router Fan Front to Back AirflowNCS-5001-FN-FR
Cisco NCS 5001 Router Fan Front to Back Airflow, spareNCS-5001-FN-FR=
Cisco NCS 5001 Router Fan Back to Front AirflowNCS-5001-FN-BK
Cisco NCS 5001 Router Fan Back to Front Airflow, spareNCS-5001-FN-BK =
Hardware Installation Guide for Cisco NCS 5000 Series Routers
3
Overview
Cisco NCS 5001
