Cisco Nexus 7706 - Switch Dimensions; Power Requirements

Switch Dimensions
HeightDepthWidthSwitch Component
15.75 inches (40.0 cm) (9
RU)
32.0 inches (81.3 cm)17.3 inches (43.9 cm)Cisco Nexus 7706 chassis
—
1
6.5 inches (16.5 cm)18.3 inches (46.5 cm)Cable management
system and front door
1
The total height of the cable management system is within the height of the chassis. The cable
management system is added to the front of the chassis but does not add any height to the chassis.
Power Requirements
Table 4: Power Requirements for the Cisco Nexus 7706 Switch Modules
TypicalMaximumQuantityComponent
——1 or 2
(same
type if
using 2)
Supervisor Modules
137 W265 WSupervisor 2 Enhanced (N77-SUP2E)
110 W150 WSupervisor 3 Enhanced (N77-SUP3E)
Cisco Nexus 7706 Hardware Installation Guide
OL-31330-01114
