QuantityWeight per UnitComponent
2
—
Supervisor Modules
4.84 lb (2.2 kg)
Supervisor A module (N9K-SUP-A)
–
5.2 lb (2.37 kg)
Supervisor A+ module (N9K-SUP-A+)
–
6.0 lb (2.72 kg)
Supervisor B module (N9K-SUP-B)
–
5.3 lb (2.39 kg)
Supervisor B+ module (N9K-SUP-B+)
–
21.9 lb (0.9 kg)System Controller Module (N9K-SC-A)
1 to 8
—
Line cards supported by N9K-C9508-FM fabric modules
11.48 lb (5.2 kg)8-port 100-Gigabit Ethernet CFP2 line card (N9K-X9408PC-CFP2)
–
10.85 lb (4.92
kg)
32-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9432PQ)
–
11.99 lb (5.44
kg)
36-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9536PQ)
–
11.48 lb (5.2 kg)36-port 40-Gigabit Ethernet QSFP+ aggregation line card
(N9K-X9636PQ)
–
10.76 lb (4.88
kg)
48-port 1/10-Gigabit Ethernet SFP+ and 4-port 40-Gigabit Ethernet
QSFP+ line card (N9K-X9464PX)
–
10.01 lb (4.54
kg)
48-port 1/10-GBASE-T plus 4-port 40-Gigabit Ethernet QSFP+ I/O
module (N9K-X9464TX)
–
10.01 lb (4.54
kg)
48-port 1/10-GBASE-T plus 4-port 40-Gigabit QSFP+ I/O module
(N9K-X9464TX2)
–
11.48 lb (5.2 kg)48-port 1/10-Gigabit Ethernet SFP+ and 4-port 40-Gigabit Ethernet
QSFP+ line card (N9K-X9564PX)
–
12.58 lb (5.7 kg)48-port 1/10-GBASE-T plus 4-port 40-Gigabit Ethernet QSFP+ I/O
module (N9K-X9564TX)
–
1 to 8
—
Line cards supported by N9K-C9508-FM-E fabric modules
12.13 lb (5.5 kg)32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9732C-EX)
–
12.75 lb (5.78
kg)
48-port 10/25-Gigabit Ethernet SFP28 and 4-port 40/100-Gigabit
Ethernet QSFP28 line card (N9K-X97160YC-EX)
–
1 to 8
—
Line cards supported by N9K-C9508-FM-R fabric modules
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
115
System Specifications
Weights and Quantities for the Chassis, Modules, Fan Trays, and Power Supplies
