Cisco Nexus 9508 - Fabric Module LEDs; Line Card LEDs

StatusColorLED
The fan tray is operational.
GreenFAN
One or more fans in this fan tray has failed.Red
No power is going to the fan tray. Verify that the even numbered fabric slot (FM
2, FM 4, or FM 6) behind the fan tray has one of the following in order to power
the fan tray:
•
Functioning fabric module (N9K-C9508-FM, N9K-C9508-FM-E,
N9K-C9508-FM-R, or N9K-C9508-FM-S)
Off
The fabric modules behind this fan tray are operational.
GreenFAB
At least one fabric module behind this fan tray is not operating.Amber
No power is going to the fabric module behind this fan tray.Off
Fabric Module LEDs
The fabric modules are located behind the fan trays.
StatusColorLED
The operator has activated this beacon (BCN) LED to identify this module
in the chassis.
When the operator activates the BCN/top LED, the BCN LED on
the covering fan module also activates (lights).
Note
BlueBCN/top
LED
This module is not being identified.Off
The fabric module is operational.GreenStatus/bottom
LED
The fabric module has a fault.Flashing red
The fabric module is booting up.Flashing amber
No power is going to the fabric module.Off
Line Card LEDs
The Beacon (BCN) and Status (STS) LEDs are located on the front left of the module, and the Link LED for
each port is located between the two rows of ports (each of these LEDs is a triangle pointing to the port above
or below the LED).
