1-9
Cisco ONS 15454 Reference Manual, R7.0.1
OL-9217-01
Chapter 1 Shelf and Backplane Hardware
1.3 1.3 Front Door
Figure 1-6 Removing the ONS 15454 Front Door
An erasable label is pasted on the inside of the front door (Figure 1-7). You can use the label to record
slot assignments, port assignments, card types, node ID, rack ID, and serial number for the ONS 15454.
Door hinge
Assembly hinge pin
Assembly hinge
Translucent
circles
for LED
viewing
38831
FAN FAIL
CRIT
MAJ
MIN
