In the event of a breakdown
C4-Picasso_II_en_Chap08_en_cas_panne_p306_ed01-2016
Lamps on the tailgate
For reassembly, carry out these operations in
reverse order.
Identify the failed bulb.

Open the boot.

Remove the access cover.

Remove the three lamp fixing screws
A
.

Disconnect the lamp connector.

Carefully remove the lamp from the outside
by pressing the retaining clip
B
.
To change a reversing lamp or direction
indicator bulb:

Use a standard pair of pliers to turn the
bulb holder a quarter turn anticlockwise,
and pull it out.

Change the bulb.
Model with LED lamps
Model with conventional bulb lamps
To change a sidelamp and brake lamp bulb:

Turn the bulb holder a quarter of a turn
anti-clockwise and pull the bulb out.

Change the bulb.
