DIMENSIONS & WEIGHTS
* Includes driver.
** Includes bodywork.
▲
On Combi models, trailer weight must be
reduced if vehicle is running at GVW to
ensure that GTW is not exceeded.
KG
Up to 7m
3
of loadspace
on Panel Vans
Up to 1200kg
payload on Panel Vans
VAN, ENTERPRISE
& COMBI
PLATFORM CAB
L1 L2
H1 H1 H2
EXTERIOR DIMENSIONS
(mm)
Length 4805 5135 5135 5016
Height (empty) – metallic suspension 1942 1942 2276 1942
Height (empty) – adjustable pneumatic rear
suspension at nominal setting
1894 1894 2204
Width (excluding door mirrors) 1895 1895 1895 1895
Width (with door mirrors folded) 1986 1986 1986 1986
Width (with door mirrors unfolded) 2194 2194 2194 2194
Wheelbase 3000 3122 3122 3122
Front overhang 975 975 975 975
Rear overhang 830 1038 1038 920
Front and rear track 1574 1574 1574 1574
LOAD COMPARTMENT DIMENSIONS (mm)
Load sill height (empty) – metallic suspension 562- 604 562- 604 562- 604
Load sill height (empty) – adjustable pneumatic
rear suspension
491- 500 491- 500 491- 500
Load length 2254 2584 2584
Maximum load compartment height 1449 1449 1750
Maximum load width between sides 1600 1600 1600
Maximum load width between wheel arches 1245 1245 1245
Sliding side door height 1293 -13 01 1293 -13 01 1293 -13 01
Sliding side door width 924 924 924
Rear door height 1272 1272 1630
Rear door width (min) 1237 1237 1237
Degree to which rear doors open 90°/180° 90°/180° 90°/180°
Load compartment volume (m
3
) – Van 5 6 7
Load compartment volume (m
3
) – Combi/Combi SX 3.5/3.0 4.1/3.7
CONVERTIBLE AREA DIMENSIONS (mm)
Usable platform length (behind the cab) 2618
Maximum width of conversion 2100
Maximum interior width between wheel arches 1245
GVW KERB WEIGHT MAXIMUM
PAYLOAD* MEDIAN MASS
IN SERVICE MAX PERMITTED WEIGHT ON FRONT AXLE** MAX PERMITTED WEIGHT ON RE AR AXLE**
MAX TRAILER
▲
GTW
WEIGHTS & PAYLOADS (kg)
PANEL VAN
HDi 90 manual L1H1 1000 2661 1673 988 1780 1400 1700 1672 4333
HDi 90 manual L1H1 1000 Enterprise 2661 1673 988 1780 1400 1700 1672 4333
HDi 125 6-speed manual L1H1 1000 2698 1698 1000 1814 1400 1700 2000 4698
HDi 90 manual L1H1 1200 2861 1673 1188 1780 1400 1700 1472 4333
HDi 125 6-speed manual L1H1 1200 2898 1698 1200 1814 1400 1700 2000 4898
HDi 90 manual L2H1 1200 2880 1692 1188 1800 1400 1700 1453 4333
HDi 125 6-speed manual L2H1 1200 2932 1732 1200 1847 1400 1700 2000 4932
HDi 125 6-speed manual L2H1 1200 Enterprise 2932 1732 1200 1847 1400 1700 2000 4932
HDi 95 6-speed manual L2H2 1200 2964 1764 1200 1878 1400 1700 2000 4964
HDi 125 6-speed manual L2H2 1200 2964 1764 1200 1878 1400 1700 2000 4964
CREW VAN
HDi 125 6-speed manual L2H1 1200 2880 1813 1067 1945
1400 1700 2000 4880
PLATFORM CAB
HDi 125 6-speed manual L2 1200 2950 1550 1400 1670
1400 1700 1930 4880
COMBI
HDi 95 6-speed manual L1H1
2780 1913 867
2013
1400 1550 2000 4780
HDi 125 6-speed manual L1H1
2780 1913 867
2013
1400 1550 2000 4780
HDi 95 6-speed manual L2H1 2810 1923 887
2044
1400 1550 2000 4810
HDi 125 6-speed manual L2H1 2810 1923 887
2044
1400 1550 2000 4810
HDi 125 6-speed manual L1H1 SX 2780 1913 867 2013 1400 1550 2000 4780
HDi 125 6-speed manual L2H1 SX 2810 1923 887
2044
1400 1550 2000 4810
HDi 160 6-speed manual L2H1 SX
2805 1953 852
2023 1400 1550 2000 4780
12
