Claas LEXION 770 2016 - Operator Controls; Right Hand Console

6
Overview Walkers
1 - Cutterbar 2 - Crop divider 3 - Crop lifter 4 - Reel 5 - Table auger 6 - Feed rake conveyor 7 - Stone trap 8 - APS Drum
9 - APS concave 10 - Threshing drum 11 - Main concave 12 - Impeller 15 - Return floor 16 - Preparation floor 17 - Upper sieve 18 - Lower sieve
19 - Clean grain cross auger 20 - Returns cross auger 21 - Cleaning fan 22 - Air duct 23 - Radial spreader 24 - Straw chopper 26 - Returns elevator 27 - Clean grain elevator
28 - Grain tank 29 - Bubble
-up auger
30 - Unloading auger 31 - Gearbox 32 - Rotor concave 33 - Rotor 34 - Chaff spreader
Overview: Straw Walker
