CJ-763E
IC10 051-9402-08 AT93C56
IC11 052-3642-00 uPD780024ASGB-
X46-8E
IC12 051-5417-08 S-80927CNMC-G8X
IC13 051-1243-00 uPC1379C
IC14 051-5420-08 S-80943CNMC-G9D
IC15 051-3040-90 NJM2125F
J1 652-0105-27 Power socket 8P
J2 652-0106-04 RCA Jack
J3 074-0892-05 DIN 5P
J4 074-0892-05 DIN 5P
L3 010-3070-56 10.5uH
L4 010-3014-66 220uH
L5 010-3407-68 NLV32 33uH J
L6 010-2285-85 150 ohm/100MHz
L7 010-2285-85 150 ohm/100MHz
L8 010-2285-85 150 ohm/100MHz
L9 010-3407-68 NLV32 33uH J
L10 010-3407-68 NLV32 33uH J
L11 010-3407-68 NLV32 33uH J
L12 010-3104-53 220 ohm/100MHz
L13 652-0088-42 7uH
L15 010-3407-68 NLV32 33uH J
L16 010-3104-53 220 ohm/100MHz
L17 010-3104-53 220 ohm/100MHz
L18 010-3104-53 220 ohm/100MHz
L19 010-3407-68 NLV32 33uH J
P3 652-0089-53 4P
PRT1 051-6903-28 IC Protector
Q6 192-4116-50 2SC4116 Y,G
Q7 192-4116-50 2SC4116 Y,G
Q8 192-4116-50 2SC4116 Y,G
Q9 192-4116-50 2SC4116 Y,G
Q10 190-1586-00 2SA1586 O,Y,G
Q11 125-2004-92 RN1402
Q12 100-1213-00 2SA1213
Q13 192-4116-50 2SC4116 Y,G
Q14 125-2004-92 RN1402
Q15 192-4116-50 2SC4116 Y,G
Q16 192-4116-50 2SC4116 Y,G
Q17 192-4116-50 2SC4116 Y,G
Q18 192-4116-50 2SC4116 Y,G
Q19 125-2004-92 RN1402
Q23 125-2004-92 RN1402
Q24 192-4116-50 2SC4116 Y,G
Q25 125-2004-92 RN1402
Q26 192-3265-00 2SC3265 O,Y
Q27 102-4440-00 2SC4440
Q28 192-4116-50 2SC4116 Y,G
R17 119-1031-15 1/10W 10k ohm
R18 119-2231-15 1/10W 22k ohm
R19 119-5621-15 1/10W 5.6k ohm
R20 119-3921-15 1/10W 3.9k ohm
R21 119-2731-15 1/10W 27k ohm
R22 652-0148-28 1/4W 100 ohm
R23 652-0148-30 1/4W 39 ohm
R24 119-1531-15 1/10W 15k ohm
R25 119-3321-15 1/10W 3.3k ohm
R26 119-1531-15 1/10W 15k ohm
R27 119-3321-15 1/10W 3.3k ohm
R28 119-1531-15 1/10W 15k ohm
R29 119-3321-15 1/10W 3.3k ohm
R30 119-1831-15 1/10W 18k ohm
R31 119-1831-15 1/10W 18k ohm
R32 119-5621-15 1/10W 5.6k ohm
R33 652-0149-10 1/4W 470 ohm
R34 652-0149-12 1/4W 680 ohm
R35 119-1041-15 1/10W 100k ohm
R36 119-4731-15 1/10W 47k ohm
R37 119-3921-15 1/10W 3.9k ohm
R38 119-3301-15 1/10W 33 ohm
ELECTRICAL PARTS LIST
Main PWB Section(B1)
C77 652-0147-15 16V 1000uF
C78 652-0148-20 16V 100uF
C79 652-0148-22 10V 33uF
C80 652-0147-15 16V 1000uF
C81 168-6835-56 0.068uF Z
C82 652-0148-23 16V 47uF
C83 166-3901-50 39pF CH
C84 652-0148-20 16V 100uF
C85 168-1022-55 1000pF K
C86 168-2222-55 2200pF K
C87 652-0148-18 50V 1uF
C87 652-0148-30 1/4W 39 ohm
C88 652-0148-24 16V 470uF
C89 652-0148-25 25V 470uF
C90 652-0089-73 250V 0.022uF
C91 652-0090-10 250V 0.068uF
C92 652-0089-74 630V 0.022uF
C93 652-0148-17 160V 3.3uF
C95 652-0148-16 400V 2.2uF
C97 168-1032-55 0.01uF K
C98 168-1032-55 0.01uF K
C99 168-1022-55 1000pF K
C100 168-2222-55 2200pF K
C101 168-2222-55 2200pF K
C102 168-2222-55 2200pF K
C103 168-2222-55 2200pF K
C105 168-2222-55 2200pF K
C106 168-2222-55 2200pF K
C107 168-1045-56 0.1uF Z
C108 652-0148-18 50V 1uF
C109 166-8211-50 820pF
C110 166-8211-50 820pF
C111 652-0148-19 16V 10uF
CCT1 050-0145-55 1/16W 10k ohm x4
CCT2 050-0145-55 1/16W 10k ohm x4
CCT3 050-0145-55 1/16W 10k ohm x4
D5 001-0517-90 1SS355
D6 001-0517-90 1SS355
D7 001-2403-90 M1F60
D8 001-0517-90 1SS355
D9 001-2410-90 D3F60
D10 001-0517-90 1SS355
D11 001-0517-90 1SS355
D12 001-0517-90 1SS355
D13 001-0517-90 1SS355
D14 001-2403-90 M1F60
D15 001-0517-90 1SS355
D16 001-0517-90 1SS355
D17 001-0517-90 1SS355
D18 001-0517-90 1SS355
D20 001-0517-90 1SS355
D20 001-2403-90 M1F60
D21 001-2403-90 M1F60
D22 001-2403-90 M1F60
D23 001-2403-90 M1F60
D24 001-2006-90 1R5GU41
D25 001-2006-90 1R5GU41
D26 001-2006-90 1R5GU41
D27 001-2005-90 OR8GU41
D28 001-2007-90 1NU41
D29 001-9203-00 TNR20V390
FIL3 060-3115-52 CKD310JB1C474ST
FIL4 060-3115-52 CKD310JB1C474ST
IC2 051-3220-00 PQ30RV21
IC3 051-0352-91 TA78L05F
IC4 051-0352-91 TA78L05F
IC5 051-2021-90 NJM386BM
IC6 051-3040-90 NJM2125F
IC7 051-5308-00 NJM2233BM
IC8 051-1621-90 MM1031XM
IC9 051-6451-90 LC74782JMH
C6 652-0148-24 16V 470uF
C7 652-0149-09 16V22uF
C8 652-0148-18 50V 1uF
C9 652-0148-20 16V 100uF
C10 168-1032-55 0.01uF K
C11 652-0148-24 16V 470uF
C12 168-1032-55 0.01uF K
C13 168-1032-55 0.01uF K
C14 652-0147-16 6.3V 2200uF
C15 652-0148-19 16V 10uF
C16 168-1032-55 0.01uF K
C17 168-1032-55 0.01uF K
C18 652-0148-23 16V 47uF
C19 168-1032-55 0.01uF K
C20 168-1032-55 0.01uF K
C21 168-1032-55 0.01uF K
C22 168-1022-55 1000pF K
C23 652-0148-20 16V 100uF
C24 652-0148-20 16V 100uF
C25 652-0148-19 16V 10uF
C26 168-1045-56 0.1uF Z
C27 652-0148-19 16V 10uF
C28 652-0148-18 50V 1uF
C29 652-0148-19 16V 10uF
C30 168-1822-55 1800pF K
C31 168-1822-55 1800pF K
C32 168-1045-56 0.1uF Z
C33 652-0148-20 16V 100uF
C34 652-0148-18 50V 1uF
C35 652-0148-19 16V 10uF
C36 652-0148-19 16V 10uF
C37 168-1032-55 0.01uF K
C38 652-0148-20 16V 100uF
C39 652-0148-18 50V 1uF
C40 168-1032-55 0.01uF K
C41 652-0148-18 50V 1uF
C42 652-0148-18 50V 1uF
C43 652-0148-23 16V 47uF
C44 168-2232-55 0.022uF K
C45 166-1201-50 12pF CH
C46 166-1201-50 12pF CH
C47 166-1201-50 12pF CH
C48 166-3901-50 39pF CH
C49 168-1222-55 1200pF K
C50 652-0147-19 50V 6.8uF BP
C51 652-0148-18 50V 1uF
C52 168-2232-55 0.022uF K
C53 652-0148-23 16V 47uF
C54 652-0148-14 16V 10uF
C55 168-1032-55 0.01uF K
C56 652-0148-22 10V 33uF
C57 168-1045-56 0.1uF Z
C58 168-1045-56 0.1uF Z
C59 168-1045-56 0.1uF Z
C60 168-1032-55 0.01uF K
C61 168-1032-55 0.01uF K
C62 652-0148-18 50V 1uF
C63 168-3332-78 0.033uF K
C64 168-3332-78 0.033uF K
C65 652-0148-23 16V 47uF
C66 652-0148-21 50V 2.2uF
C67 168-3332-78 0.033uF K
C68 168-1032-55 0.01uF K
C69 168-1032-55 0.01uF K
C70 652-0105-16 100V 0.0056uF
C71 652-0148-23 16V 47uF
C72 652-0148-18 50V 1uF
C73 652-0148-20 16V 100uF
C74 652-0148-24 16V 470uF
C75 168-4722-55 4700pF K
C76 042-0397-59 35V 1uF(TAN)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
All PWB consists of one piece of PWB.
R39 119-1021-15 1/10W 1k ohm
R40 119-2731-15 1/10W 27k ohm
R41 119-3931-15 1/10W 39k ohm
R42 119-4731-15 1/10W 47k ohm
R43 119-2231-15 1/10W 22k ohm
R44 119-1031-15 1/10W 10k ohm
R45 119-4721-15 1/10W 4.7k ohm
R46 119-1821-15 1/10W 1.8k ohm
R47 119-1031-15 1/10W 10k ohm
R49 119-1531-15 1/10W 15k ohm
R50 119-7501-15 1/10W 75 ohm
R51 119-7501-15 1/10W 75 ohm
R52 652-0149-11 1/4W 4.7 ohm
R53 652-0149-11 1/4W 4.7 ohm
R54 119-2211-15 1/10W 220 ohm
R55 119-3921-15 1/10W 3.9k ohm
R56 119-3311-15 1/10W 330 ohm
R57 119-0000-05 1/10W 0 ohm JW
R58 119-2211-15 1/10W 220 ohm
R59 119-2731-15 1/10W 27k ohm
R60 119-2231-15 1/10W 22k ohm
R61 119-4711-15 1/10W 470 ohm
R62 119-4721-15 1/10W 4.7k ohm
R63 119-1021-15 1/10W 1k ohm
R64 119-1031-15 1/10W 10k ohm
R65 119-0000-05 1/10W 0 ohm JW
R66 119-0000-05 1/10W 0 ohm JW
R67 119-0000-05 1/10W 0 ohm JW
R68 119-6811-15 1/10W 680 ohm
R69 119-0000-05 1/10W 0 ohm JW
R71 119-1041-15 1/10W 100k ohm
R72 119-1041-15 1/10W 100k ohm
R73 119-1031-15 1/10W 10k ohm
R73 119-1031-15 1/10W 10k ohm
R75 119-4701-15 1/10W 47 ohm
R118 119-2211-15 1/10W 220 ohm
R120 119-1031-15 1/10W 10k ohm
R121 119-1031-15 1/10W 10k ohm
R122 119-1531-15 1/10W 15k ohm
R123 119-4731-15 1/10W 47k ohm
R124 119-1021-15 1/10W 1k ohm
R125 119-1521-15 1/10W 1.5k ohm
R126 119-2731-15 1/10W 27k ohm
R127 119-2231-15 1/10W 22k ohm
R128 119-4721-15 1/10W 4.7k ohm
R129 119-3931-15 1/10W 39k ohm
RY1 014-0565-01 Relay
S1 013-6002-50 SKHVBC 6 x6
S2 013-6002-50 SKHVBC 6 x6
S3 013-6002-50 SKHVBC 6 x6
S4 013-6002-50 SKHVBC 6 x6
S5 013-6002-50 SKHVBC 6 x6
S6 013-6002-50 SKHVBC 6 x6
S7 013-6002-50 SKHVBC 6 x6
T1 652-0089-52 Drive trans
T2 652-0106-05 Fliback trans
TC1 004-1580-10 30pF GRN
TR1 009-9002-00 1mH
VR1 012-3808-02 1k ohm B
VR2 012-3808-05 4.7k ohm B
VR3 012-3808-06 10k ohm B
VR4 012-3808-01 470 ohm B
VR5 016-9900-35 500 ohm
VR6 016-9900-36 100k ohm
X1 060-1037-90 8MHz
X2 061-1086-50 14.31818MHz
PWB 652-0149-15 PWB(Without
components)
R76 119-6831-15 1/10W 68k ohm
R77 119-2211-15 1/10W 220 ohm
R78 119-1011-15 1/10W 100 ohm
R79 032-0125-00 1/4W 15k ohm
R80 119-1331-15 1/10W 13k ohm
R81 119-5621-15 1/10W 5.6k ohm
R82 652-0148-29 1/4W 330 ohm
R83 119-2231-15 1/10W 22k ohm
R84 119-4721-15 1/10W 4.7k ohm
R85 119-1831-15 1/10W 18k ohm
R86 119-1831-15 1/10W 18k ohm
R88 119-3331-15 1/10W 33k ohm
R89 119-1531-15 1/10W 15k ohm
R90 119-2731-15 1/10W 27k ohm
R91 119-1821-15 1/10W 1.8k ohm
R92 119-3911-15 1/10W 390 ohm
R93 114-3391-11 1W 3.3 ohm
R94 119-2211-15 1/10W 220 ohm
R95 119-1031-15 1/10W 10k ohm
R96 119-1531-15 1/10W 15k ohm
R97 119-2711-15 1/10W 270 ohm
R98 119-2231-15 1/10W 22k ohm
R99 119-2211-15 1/10W 220 ohm
R100 119-1031-15 1/10W 10k ohm
R101 119-5621-15 1/10W 5.6k ohm
R102 652-0148-31 1/4W 47 ohm
R103 114-3901-11 1W 39 ohm
R104 119-5631-15 1/10W 56k ohm
R105 111-1091-81 1/2W 1 ohm
R106 119-1031-15 1/10W 10k ohm
R107 652-0088-49 1/4W 22k ohm
R108 652-0088-50 1/4W 47k ohm
R109 032-0101-89 1/2W 180k ohm
R110 032-0101-90 1/2W 820k ohm
R117 119-6811-15 1/10W 680 ohm
Q1 192-4116-50 2SC4116 Y,G
Q2 190-1586-00 2SA1586 O,Y,G
Q3 192-4116-50 2SC4116 Y,G
Q4 652-0148-41 2SA1313 Y
Q5 102-4549-00 2SC4549 M,L,K
R1 119-3321-15 1/10W 3.3k ohm
R2 119-1031-15 1/10W 10k ohm
R3 119-2211-15 1/10W 220 ohm
R4 119-1031-15 1/10W 10k ohm
R5 119-2211-15 1/10W 220 ohm
R6 119-1021-15 1/10W 1k ohm
R7 119-1031-15 1/10W 10k ohm
C1 652-0148-38 35V 10uF
C2 652-0148-18 50V 1uF
C3 652-0147-14 35V 470uF
C4 166-1511-50 150pF CH
C5 652-0147-13 16V 470uF
D1 001-0517-90 1SS355
D2 001-4305-32 UDZSTE-17 18B
D3 001-4301-21 HZU3.9B2
D4 652-0148-39 30DF2
IC1 051-1508-90 M5291FP
L1 652-0089-76 EMI Coil
L2 652-0089-30 120uH
Switching PWB Section(B2)
R8 119-1031-15 1/10W 10k ohm
R9 652-0089-78 1/2W 0.15 ohm
R10 652-0089-78 1/2W 0.15 ohm
R11 652-0148-37 1/4W 2.2k ohm
R12 119-1521-15 1/10W 1.5k ohm
R13 652-0105-20 1/4W 1.5k ohm
R14 652-0105-20 1/4W 1.5k ohm
R15 119-8221-15 1/10W 8.2k ohm
R16 652-0105-17 1/4W 27 ohm
R119 119-1221-15 1/10W 1.2k ohm
PWB 652-0149-15 PWB(Without
components)
C96 652-0089-86 100V 0.22uF
L14 652-0089-81 150uH
P4 652-0089-82 2P
P5 652-0090-04 CRT Socket
Q29 102-3620-00 2SC3620
Socket PWB Section(B3)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R116 652-0088-53 1/2W 120k ohm
VR7 652-0147-20 1M ohm B
PWB 652-0149-15 PWB(Without
components)
R111 652-0089-83 1W 5.6k ohm
R112 652-0148-32 1/4W 10k ohm
R113 032-0101-01 1/2W 100k ohm
R114 652-0105-20 1/4W 1.5k ohm
R115 652-0088-54 1/2W 470k ohm
To Next Page
